[C1-N9K-C93180LC-EX] Cisco ONE Nexus 93180LC-EX Switch - L3

Ports 24 x 40/50 Gigabit QSFP+ + 6 x 40 Gigabit / 100 Gigabit QSFP28
Performance Bandwidth: 3.6 Tbps
RAM 24 GB
Built-in Devices 64 GB SSD
Expansion / Connectivity
Interfaces 24 x 40Gbit/50Gbit LAN QSFP+ downlink ¦ 6 x 100Gbit/40Gbit LAN QSFP28 uplink ¦ 1 x management RJ-45 ¦ 1 x management SFP+ ¦ 1 x USB ¦ 1 x serial (RS-232)
Power
Power Device Internal power supply - hot-plug
Installed Qty 0 (installed) / 2 (max)
Power Redundancy Optional
Power Redundancy Scheme 1+1
Miscellaneous
Included Accessories Fixed accessory kit
Compliant Standards CISPR 22 Class A, CISPR 24, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, RoHS, GB 4943, Directive 2004/108/EC, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2006/95/EC, VCCI Class A, KN22 Class A, EN 300386, EN61000-3-2, EN61000-3-3, EN 55022 Class A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second Edition, KN 61000-4
Dimensions & Weight
Width 17.3 in
Depth 22.5 in
Height 1.7 in
Weight 17.2 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
