[LSI00264] Broadcom LSI Logic LSI00264 LSIiBBU08 Battery Backup Unit For MegaRaid SAS 9260 and 9280 Series Controllers
Specifications
Brand: LSI
Part Number: LSI00264
Alt MPN: LSIIBBU08
Application / Usage: Storage Controller
Battery Rechargeable: Yes
Battery Size: Proprietary Battery Size
Battery Chemistry: Lithium Polymer (Li-Polymer)
Battery Capacity: 1590 mAh
Output Voltage: 3.7V DC
Dimensions: 6.0 x 6.0 x 2.0 inch / 15.24 x 15.24 x 5.10 cm
Weight: 1.0 lbs / 0.45 kg
Features
Helps protects integrity of cache in the event of power or server failure
Higher maximum ambient temperature tolerance than previous generation battery backup units
Multiple modes of operation and retention times
Transparent and shorter learning cycles
For use on all existing 6Gb/s MegaRAID controllers
Customize mounting location in chassis with remote mounting options
Compatibility
The LSIiBBU08 connects remotely to the following SAS RAID controllers using a 12-inch cable or, where applicable (*), a 12-inch cable and a remote interposer board that are sold separately in a Remote Battery Kit:
MegaRAID SAS 9260-4i*
MegaRAID SAS 9260-8i*
MegaRAID SAS 9260-16i
MegaRAID SAS 9261-8i
MegaRAID SAS 9280-4i4e
MegaRAID SAS 9280-8e
MegaRAID SAS 9280-16i4e
MegaRAID SAS 9280-24i4e
