[eSFP-GE-ZX100-SM1550] Huawei Optical Transceiver, eSFP, GE, Single-mode Module (1,550 nm,100 km, LC)[02315206]
Basic Information
Module name: eSFP-GE-ZX100-SM1550
Part Number: 02315206
Model: eSFP-GE-ZX100-SM1550
Form factor: eSFP
Application standard: 1000BASE-ZX
Connector type: LC
Optical fiber type: SMF
Working case temperature [°C(°F)]: 0°C to 70°C (32°F to 158°F)
Transmission rate [bit/s]: 1 Gbit/s
Target transmission distance [km]: Single-mode fiber: 100 km
Transmitter Optical Characteristics
Center wavelength [nm]: 1550 nm
Maximum Tx optical power [dBm]: 5 dBm
Minimum Tx optical power [dBm]: 0 dBm
Minimum extinction ratio [dB]: 9.5 dB
Receiver Optical Characteristics
Rx sensitivity [dBm]: -30.0 dBm
Overload power [dBm]: -9.0 dBm
