[EHWIC-3G-EVDO-S] Cisco 3900 Router EHWIC WAN Card EHWIC-3G-EVDO-S

Device Type

Interface module

Form factor

Single wide Cisco 3G WWAN EHWIC form factor

Specifications

Bands

850, 900, 1900, and 2100 MHz

DL/UP Speeds

7.2 Mbps/5.76 Mbps

External Interfaces

• RJ-45 interface for use with diagnostics and monitoring tools

• Two TNC connectors with main and diversity RF port for antenna connection. Diversity port can also support GPS.

• EHWIC-3G-HSPA+7, EHWIC-3G-HSPA+7-A, EHWIC-3G-HSPA-U supports main and diversity antenna connector

• EHWIC-3G-EVDO-S, EHWIC-3G-EVDO-V, EHWIC-3G-EVDO-B supports main and diversity antenna connector

Physical Dimensions (H x W x D)

0.75 x 3.08 x 4.9 in. (1.9 x 7.8 x 12.4 cm)

Weight

0.24 lb (3.84 oz)

Subscriber Identity Module (SIM) Card

SIM card socket; compliant with ISO-7816-2 (SIM mechanical)

Power

4.5W maximum

Supported Platforms

Modular Cisco 1900, 2900 and 3900 Integrated Services Routers G2

Software Compatibility

Modular Cisco 1900, 2900,and 3900 series Integrated Services Routers supported with Cisco IOS Software release:

• Cisco IOS Software feature set: Universal IOS image

• EHWIC-3G-EVDO-S supported with 15.1(3)T or later

Key Features Include

• Auto-Switch Failover Between Primary & Backup Link

• Multichannel-interface-processor (MIP) profile configuration

• CDMA Data Retry

• 3G SNMPv2 MIBs and Traps

• Remotely initiated data call back using voice

• Remotely initiated data call back using SMS

• Remote firmware upgrade over 3G

• Virtual diagnostic monitoring

• MEP lock/unlock capability

• SIM lock/unlock capability

SMS/GPS

• Send and receive SMS (max. 160 characters)

• Standalone GPS

MIBs

• 3G MIB

• ENTITY MIB

• IF MIB

• 3G WWAN MIB persistence

Network Management and Diagnostics

• In-band and out-of-band management using Telnet (Cisco IOS Software command-line interface [CLI]) and Simple Network Management Protocol (SNMP), including MIB II and other extensions

• Industry-standard 3G diagnostics and monitoring tools (QUALCOMM CDMA Air Interface Tester [CAIT] and Spirent Universal Diagnostic Monitor [UDM])

Modem Information

• Modem form factor: Embedded Peripheral Component Interconnect (PCI) minicard
