[57-0000075-01] Brocade Transceiver 10GB SFP+ SR Module (MMF, 850nm, 300m, LC, DDMI)
Form Factor SFP+ Data Rate 10Gb/s
Wavelength 850 nm Fiber Type MMF
Max Distance 300 m Optical Components VCSEL/PIN
Transmitter Power -6 ~ -1 dBm Extinction ratio > 3.5 dB
Receiver Sensitivity < -10 dBm Receiver Overload > 0.5 dBm
Connector LC Duplex Digital Diagnostic Monitoring Yes
Environment Operating: 0°C to 70°C
Storage: -40°C to 85°C Weight 0.03 kg
Application 10GBASE-SR/10GBASE-SW Ethernet
10G Fiber Channel
10GbE Data Center Switches and Routers
