[MCX614105A-VCAT] Mellanox ConnectX-6 EN adapter card kit, 200GbE, single-port QSFP56, Socket Direct 2x PCIe3.0 x16, tall brackets

NVIDIA MCX614105A-VCAT ConnectX-6 EN Adapter Card 200GbE Single-Port QSFP56 Socket Direct 2x PCIe 3.0 x16 Tall Brackets

ConnectX-6 EN Card 200GbE Ethernet Adapter Card

World's first 200GbE Ethernet network interface card, enabling industry-leading performance smart offloads and in-network computing for Cloud, Web 2.0, Big Data, Storage and Machine Learning applications.

ConnectX-6 EN provides up to two ports of 200GbE connectivity, sub 0.8usec latency and 215 million messages per second, enabling the highest performance and most flexible solution for the most demanding data center applications.

ConnectX-6 is a groundbreaking addition to the ConnectX series of industry-leading adapter cards. In addition to all the existing innovative features of past versions, ConnectX-6 offers a number of enhancements to further improve performance and scalability, such as support for 200/100/50/40/25/10/1 GbE Ethernet speeds and PCIe Gen 4.0. Moreover, ConnectX-6 Ethernet cards can connect up to 32-lanes of PCIe to achieve 200Gb/s of bandwidth, even on Gen 3.0 PCIe systems.

Features
Up to 200GbE connectivity per port
Maximum bandwidth of 200Gb/s
Up to 215 million messages/sec
Sub 0.8usec latency
Block-level XTS-AES mode hardware encryption
Optional FIPS-compliant adapter card
Support both 50G SerDes (PAM4) and 25G SerDes (NRZ) based ports
Best-in-class packet pacing with sub-nanosecond accuracy
PCIe Gen4/Gen3 with up to x32 lanes
RoHS compliant
ODCC compatible

Benefits
Most intelligent, highest performance fabric for compute and storage infrastructures
Cutting-edge performance in virtualized HPC networks including Network Function Virtualization (NFV)
Advanced storage capabilities including block-level encryption and checksum offloads
Host Chaining technology for economical rack design
Smart interconnect for x86, Power, Arm, GPU and FPGA-based platforms
Flexible programmable pipeline for new network flows
Enabler for efficient service chaining
Efficient I/O consolidation, lowering data center costs and complexity
