[81Y1658] IBM 81Y1658 81Y1657 FC 16Gb 1-Port PCIE 3.0 x8 Emulex LPe16000 Controller

Technical specifications

The Brocade 16Gb FC Single-port and Dual-port HBAs have the following specifications:

Host interface: PCI Express Gen 2 x8
Data rate: 14.025 Gbps (1600 MBps); 8.5 Gbps (800 MBps); 4.25 Gbps (400 MBps); 2.125 Gbps (200 MBps) autosensing (per port); full duplex
Performance: over 500,000 IOPS per port (1,000,000 IOPS per dual-port adapter)
Boot support: Boot from SAN, Fabric-based Boot LUN Discovery
Protocols: SCSI-FCP, FCP-2, FCP-3, FC-SP
Topology: Point-to-point (N_Port), switched fabric (N_Port)
N_Port Trunking of 2×16 Gbps links into a single logical 32 Gbps link
Supported media: Brocade 16 Gbps and 8 Gbps Fibre Channel LC-style pluggable (SFP+), SWL (850 nm), hot-pluggable
Distance support:
15 m at 16 Gbps on 62.5/125 µm (OM1) Multi-Mode Fiber (MMF)
35 m at 16 Gbps on 50/125 µm OM2 MMF
100 m at 16 Gbps on 50/125 µm OM3 MMF
125 m at 16 Gbps on 50/125 µm OM4 MMF
Management software:
Brocade Host Connectivity Manager (HCM)
Brocade Configuration Utility (BCU) Command Line Interface (CLI)
Brocade Network Advisor
